FF01 通通版美标呆锁(TTLock)

FF01 通通版美标呆锁(TTLock)

No. FD-047 Views 4

US-standard deadbolt · easy install · fingerprint/PIN/card · TTLock ecosystem

Price TBA

Project-based pricing · Contact us for a quote

WhatsApp Get a Quote
Dry-battery model · batteries not included · Ships without batteries via standard lines (faster & cheaper) — use local AA batteries on arrival
Share:

TTLock Version · Platform Ecosystem

The TTLock version runs on the global TTLock ecosystem, compatible with rental, hotel and public-housing management apps. Dynamic PINs, remote eKeys and cloud-synced access logs let operators issue and revoke access in bulk by lease term — ideal for hotels, serviced apartments and large rental projects, and instantly familiar to overseas teams already using TTLock.

Version Comparison · One Hardware, Four Ecosystems

VersionPlatformNetworkingBest For
TTLock VersionCurrentTTLock App (rental / hotel / housing ecosystem)Bluetooth / WiFi / Gateway / NB-IoTHotels, apartments, rental projects
Tuya VersionTuya Smart App (smart-home linkage)Tuya Bluetooth / Tuya WiFi / Zigbee / RemoteHomes, B&Bs, smart-home scenesView →

Product Size

FF01 通通版美标呆锁(TTLock) size

Networking (Optional)

Bluetooth WiFi Gateway NB-IoT

Specifications

Platform
TTLock App (rental / hotel / public-housing ecosystem)
Unlock
App · PIN · fingerprint · IC card · key · remote
Fingerprint
Semiconductor sensor, 50 capacity
FAR
<0.001%
FRR
<1.0%
Cards
1000 cards (MIFARE M1)
PIN Codes
250 custom & permanent · unlimited dynamic
Local Log
2000 records (incl. unlock history)
Bluetooth
Bluetooth 5.0 BLE
Networking
Bluetooth / WiFi / Gateway / NB-IoT
App Support
Android 4.3+ · iOS 7.0+
Power
4×AA alkaline batteries
Low Battery Alert
4.8V±0.1V
Voltage
4.5~9V
Standby Current
90μA
Working Current
<200mA
Unlock Speed
≈1.5s
Temperature
-20℃ ~ 70℃
Keypad
Capacitive touch keypad
Front Panel
155 × 64 × 19mm (glass panel)
Rear Panel
165 × 68 × 30mm (safety knob)
Unit Weight
1.084kg
Gift Box
240×247×85mm
Carton
500×450×280mm
Qty per Carton
10 pcs / 13.99kg

Accessories & Extensions

Universal add-ons for all FANDAN smart locks — pick as needed

Gateway

Bridge between Bluetooth locks and the server: sync unlock records, alarm reports & remote management

Wireless Key R1

Bluetooth remote — tap to unlock from a distance

Card Encoder

Hotel-style card issuing: master / floor / building / room cards (MiFare S50)

Door Sensor

Auto-lock on close, with real-time door status

Elevator Control

App-managed elevator access via IC cards

Fingerprint Enroller

Remote fingerprint enrollment & push — ideal with NB-IoT locks and public housing
